9–33 VOLT MODEL 49 L.E.D REAR DIRECTION INDICATOR, STOP LAMP, REVERSE AND TRIPLE TAIL LAMP

Part No. 94958
The most popular rear combination lamp referred to as the ‘Jumbo’ lamp has dominated the transport industry in Australasia. The Model 49 fits the same footprint as its predecessor the Model 48, & features a continuous ‘Neon’ like LED light-pipe framing the lamp’s borders, meeting the ADR performance regulation for tail lamps. The stop, indicator & reverse functions are activated on the inside of the tail lamp with high quality optics to gain the attention of those following.
The most popular rear combination lamp referred to as the ‘Jumbo’ lamp has dominated the transport industry in Australasia. The Model 49 fits the same footprint as its predecessor the Model 48, & features a continuous ‘Neon’ like LED light-pipe framing the lamp’s borders, meeting the ADR performance regulation for tail lamps. The stop, indicator & reverse functions are activated on the inside of the tail lamp with high quality optics to gain the attention of those following.

Specifications

Technical Information
INPUT VOLTAGE RANGE9-33 Volt
CURRENT DRAWIndicator: 0.3A, Stop: 0.3A, Tail: 0.34A, Reverse: 0.18A
SIZE600 x 110mm
CANDELA RATING40
ADR1/00 AR-E9-00-16426, 6/00 2a-E9-01.16424, 47/00 1A-E9-02.6612, 49/00 R1-S1-E9-02.16425
Dimensions
