12 Volt Sealed Reverse Lamp Kit with In-built Retro Reflector and Vinyl Grommet
12 Volt Sealed Reverse Lamp Kit with In-built Retro Reflector and Vinyl Grommet
Part No.
94518
72
Model 45 lamps can be flush mounted in a vinyl grommet or combined in clusters within
the thermoplastic rubber body of the modules. The uniquely designed shock-mounted
bulbs absorb shock from all directions to prolong the life of the lamp.
Share this page
The virtually unbreakable polycarbonate lenses and sonically sealed housings prevent
moisture and corrosive material from entering the lamp
The reverse lamp includes an in-built retro reflector and all lamps are available in 12 and 24 volt
Technical Information
| CURRENT DRAW | 1.85A at 12V |
|---|---|
| ECE | Vertical: 15518 15537 |
| ADR | Vertical: 1/00 47/00 |
Drawings
Product Comprises of
| 1. | 94512 1 x 24V sealed rear stop/tail lamp |
|---|---|
| 2. | 94580 1 x vinyl grommet |
| 3. | 94590 1 x plug and leads |
Spare Parts
