Narva | 9–33 VOLT MODEL 41 L.E.D REAR DIRECTION INDICATOR AND STOP/TAIL LAMP

9–33 VOLT MODEL 41 L.E.D REAR DIRECTION INDICATOR AND STOP/TAIL LAMP

9–33 VOLT MODEL 41 L.E.D REAR DIRECTION INDICATOR AND STOP/TAIL LAMP

Part No. 94160BL
16 Designed around the popular Model 42 range of rear combination lamps, the Model 41 family boasts all the same features as their larger counterpart but in a smaller more compact package
Share this page
Virtually unbreakable polycarbonate lens Grey housing 0.5m hard wired cable

Technical Information

INPUT VOLTAGE RANGE9-33 Volt
CURRENT DRAWIndicator: 0.42A, Stop: 0.42A, Tail: 0.09A
LP RATINGIP66 and IP67
SIZE362 x 100mm
CANDELA RATING51
ADR6/00 2a-E9-01.1625 (cat 2a), 49/00 R1-S1-E9-02.6256

Drawings

Product Comprises of

1.94145
2.94147
3.94192
