10–30 VOLT MODEL 20 L.E.D SIDE MARKER LAMP OR FRONT END OUTLINE MARKER LAMP (AMBER)

Part No. 92002
87 Model 20 L.E.D lamps are sonically sealed acrylic lamps with a multi-voltage circuitry of 10–30V and hard-wired leads. Less expensive than the flush mounted polycarbonate 18 series lamps, the 20 series are a low profile surface mounted alternative. These lamps meet the requirements of ADR 74/00 as an amber side marker and are ideal for
87 Model 20 L.E.D lamps are sonically sealed acrylic lamps with a multi-voltage circuitry of 10–30V and hard-wired leads. Less expensive than the flush mounted polycarbonate 18 series lamps, the 20 series are a low profile surface mounted alternative. These lamps meet the requirements of ADR 74/00 as an amber side marker and are ideal for

Specifications

Technical Information
INPUT VOLTAGE RANGE10-30 Volt
CURRENT DRAW0.04A
LP RATINGIP66 and IP68
SIZE124 x 39mm
CANDELA RATING37
ADR47/00 31151, 49/00 31149, 74/00 31152
Dimensions
