Narva | 10–30 VOLT MODEL 8 L.E.D FRONT END OUTLINE MARKER LAMP (WHITE)

10–30 VOLT MODEL 8 L.E.D FRONT END OUTLINE MARKER LAMP (WHITE)

10–30 VOLT MODEL 8 L.E.D FRONT END OUTLINE MARKER LAMP (WHITE)

Part No. 90810
88 Model 8 LED lamps comply with the ADR requirements for front & rear end outline marker lamps. All lamps feature multi-voltage circuitry to suit 12 or 24 volt operation & hard-wired cable. A gasket, mounting screws & screw caps are included. While the low profile nature of these lamps protects them from damage, so too does the virtually
Share this page
A recess mounted lamp with gasket, mounting screws and screw caps 0.5m hard wired cable Rated to 100,000 hours of L.E.D life

Technical Information

INPUT VOLTAGE RANGE10-30 Volt
CURRENT DRAW 0.03A
LP RATINGIP66 and IP68
SIZE90 X 25mm
CANDELA RATING11
ADR49/00 39859

Drawings
