LED Daytime Running Lamp Assembly with Park Function and Direction Indicator
Part No. 71994
9-33V 90mm diameter Automatically turns on with ignition and switches to park
function with park lamps. Powerful L.E.Ds offer enhanced daytime visibility for
oncoming traffic and the inclusion of a direction indicator provides a compact all
in one hybrid lamp.
9-33V 90mm diameter Automatically turns on with ignition and switches to park
function with park lamps. Powerful L.E.Ds offer enhanced daytime visibility for
oncoming traffic and the inclusion of a direction indicator provides a compact all
in one hybrid lamp.
Specifications
Technical Information
| INPUT VOLTAGE RANGE | 9-33V |
|---|---|
| CURRENT DRAW | DRL: 0.35A at 9–33V Park Lamp: 0.10A at 9–33V Indicator: 0.30A at 9–33V |
| IP RATING | IP66 |
| SIZE | 90mm |
| ADR | 76/00 RL-E1-67R-00.3713 49/00 A-E1-7R-02.3713 6/00 1-E1-6R-01.3713 |
| COMPRISES | Die-cast aluminium housing with easy beam adjustment; Fully sealed (IP66); |
Dimensions
