9–33 VOLT MODEL 56 L.E.D REVERSE LAMP (RED) WITH RED L.E.D TAIL RING

9–33 VOLT MODEL 56 L.E.D REVERSE LAMP (RED) WITH RED L.E.D TAIL RING

Part No. 95628
0 With a high end look and quality chrome finish the new Model 56 boasts an elegant design for manufacturers who are looking for something distinctive and unique.
Share this page
Acrylic lens Includes mounting screws and an integrated gasket on the surface of the mounting base 0.5m hard wired sheathed cable and contoured chrome cover

Technical Information

INPUT VOLTAGE RANGE9-33 Volt
CURRENT DRAW Reverse 0.29A, Tail: 0.1A
SIZE155mm diameter
CANDELA RATING41
ADR1/00 AR 00 E9 11622, 49/00 R1 02 E9 11622

Drawings
