9–33 VOLT MODEL 49 L.E.D REAR DIRECTION INDICATOR STOP LAMP AND TWIN TAIL LAMPS

9–33 VOLT MODEL 49 L.E.D REAR DIRECTION INDICATOR STOP LAMP AND TWIN TAIL LAMPS

Part No. 94940
The most popular rear combination lamp referred to as the ‘Jumbo’ lamp has dominated the transport industry in Australasia. The Model 49 fits the same footprint as its predecessor the Model 48, & features a continuous ‘Neon’ like LED light-pipe framing the lamp’s borders, meeting the ADR performance regulation for tail lamps. The stop, indicator & reverse functions are activated on the inside of the tail lamp with high quality optics to gain the attention of those following.
Share this page
Virtually unbreakable polycarbonate lens Direct retrofit for standard Jumbo rear lamps Bold 'Neon' like L.E.D light-pipe tail light gives striking and modern appearance Includes In-built retro reflector and 0.5m hard wired cable

Technical Information

INPUT VOLTAGE RANGE9-33 Volt
CURRENT DRAWIndicator: 0.3A, Stop: 0.3A, Tail: 0.34A, Reverse: 0.18A
SIZE390 x 110mm
CANDELA RATING30
ADR6/00 TBA, 47/00 TBA, 49/00 TBA

Drawings

Product Comprises of

1.94900
2.94908
3.94990
4.94993
