Narva | 9–33V MODEL 48 LED REVERSE STOP/TAIL AND REAR DIRECTION INDICATOR LAMP VERTICAL MOUNTING

9–33V MODEL 48 LED REVERSE STOP/TAIL AND REAR DIRECTION INDICATOR LAMP VERTICAL MOUNTING

9–33V MODEL 48 LED REVERSE STOP/TAIL AND REAR DIRECTION INDICATOR LAMP VERTICAL MOUNTING

Part No. 94856V
Model 48 L.E.D lamps, commonly referred to as “Jumbos” are arguably the most popular rear combination lamp design in Australasia.
Share this page
Virtually unbreakable polycarbonate lens 0.5m hard wired cable In-built retro reflector Black housing and security caps

Technical Information

INPUT VOLTAGE RANGE9-33 Volt
CURRENT DRAWIndicator: 0.42A, Stop/Tail: 0.22/0.02A, Reverse: 0.32A
LP RATINGIP66 and IP68
SIZE601 X 131mm
CANDELA RATING83
ADR1/00 AR-E9-00-1155, 6/00 2a-E9-01.1938, 47/00 1B-E9-02.1535, 49/00 R1-S1-E9-02.6594

Drawings

Product Comprises of

1.94800
2.94808
3.94816V
4.94896
