9–33 VOLT MODEL 48 L.E.D REAR DIRECTION INDICATOR AND STOP/TAIL LAMP
9–33 VOLT MODEL 48 L.E.D REAR DIRECTION INDICATOR AND STOP/TAIL LAMP
Part No.
94840
Model 48 L.E.D lamps, commonly referred to as “Jumbos” are arguably the most popular
rear combination lamp design in Australasia.
Share this page
Virtually unbreakable polycarbonate lens
0.5m hard wired cable
In-built retro reflector
Black housing and security caps
Technical Information
| INPUT VOLTAGE RANGE | 9-33 Volt |
|---|---|
| CURRENT DRAW | Indicator: 0.42A, Stop/Tail: 0.22/0.02A |
| LP RATING | IP66 and IP68 |
| SIZE | 400 x 131mm |
| CANDELA RATING | 63 |
| ADR | 6/00 2a-E9-01.1938, 47/00 1B-E9-02.1535, 49/00 R1-S1-E9-02.6594 |
Drawings
Product Comprises of
| 1. | 94800 |
|---|---|
| 2. | 94808 |
| 3. | 94893 |
