Narva | 9–33 VOLT MODEL 45 L.E.D REAR STOP/TAIL AND DIRECTION INDICATOR LAMP (RED/AMBER)

9–33 VOLT MODEL 45 L.E.D REAR STOP/TAIL AND DIRECTION INDICATOR LAMP (RED/AMBER)

9–33 VOLT MODEL 45 L.E.D REAR STOP/TAIL AND DIRECTION INDICATOR LAMP (RED/AMBER)

Part No. 94524BL
89 Model 45 combination lamp that offers both stop/tail and indicator within one lamp. This feature allows the manufacturer to use fewer lamps or create a signature appearance by multiplying the visual performance of each lamp, and a uniformed style by offering lamps with all clear lenses when matched with the reverse.
Share this page
Virtually unbreakable polycarbonate lens Includes lamp only

Technical Information

INPUT VOLTAGE RANGE9-33 Volt
CURRENT DRAWIndicator: 0.26A, Stop: 0.26A, Tail: 0.04A
SIZE160 X 112mm
CANDELA RATING42
ADR49/00 R1-S1 02 E9 6113, 6/00 2a 01 E9 6113

Drawings

Product Comprises of

1.94524
