Narva | 12 Volt Sealed Rear Stop/Tail Lamp Kit (Red) with Vinyl Grommet

12 Volt Sealed Rear Stop/Tail Lamp Kit (Red) with Vinyl Grommet

12 Volt Sealed Rear Stop/Tail Lamp Kit (Red) with Vinyl Grommet

Part No. 94510
72 Model 45 lamps can be flush mounted in a vinyl grommet or combined in clusters within the thermoplastic rubber body of the modules. The uniquely designed shock-mounted bulbs absorb shock from all directions to prolong the life of the lamp.
Share this page
The virtually unbreakable polycarbonate lenses and sonically sealed housings prevent moisture and corrosive material from entering the lamp The reverse lamp includes an in-built retro reflector and all lamps are available in 12 and 24 volt

Technical Information

CURRENT DRAW1.85/0.44A
ECEVertical: 15512 Horizontal: 35671
ADRVertical: 49/00 Horizontal: 49/00

Drawings

Product Comprises of

1.94508 1 x 12V sealed rear stop/tail lamp
2.94580 1 x vinyl grommet
3.94590 1 x plug and leads
