9–33V MODEL 41 LED REVERSE STOP/TAIL & REAR DIRECTION INDICATOR LAMP FOR VERTICAL MOUNTING
9–33V MODEL 41 LED REVERSE STOP/TAIL & REAR DIRECTION INDICATOR LAMP FOR VERTICAL MOUNTING
Part No.
94178V
16
Designed around the popular Model 42 range of rear combination lamps, the Model 41
family boasts all the same features as their larger counterpart but in a smaller more
compact package
Share this page
Virtually unbreakable polycarbonate lens
In-built retro reflector
0.5m hard wired cable
Grey housing
Technical Information
| INPUT VOLTAGE RANGE | 9-33 Volt |
|---|---|
| CURRENT DRAW | Indicator: 0.42A Stop: 0.42A Tail: 0.09A, Reverse: 0.34A |
| LP RATING | IP66 and IP67 |
| SIZE | 544 x 100mm |
| CANDELA RATING | 71 |
| ADR | 1/00 AR-E9-00.1136, 6/00 2a-E9-01.1625 (cat 2a), 49/00 R1-S1-E9-02.6256 |
Drawings
Product Comprises of
| 1. | 94145 |
|---|---|
| 2. | 94147 |
| 3. | 94151V |
| 4. | 94193 |
