Narva | 9–33V MODEL 41 LED REVERSE STOP/TAIL & REAR DIRECTION INDICATOR LAMP

9–33V MODEL 41 LED REVERSE STOP/TAIL & REAR DIRECTION INDICATOR LAMP

9–33V MODEL 41 LED REVERSE STOP/TAIL & REAR DIRECTION INDICATOR LAMP

Part No. 94178H
38 FOR HORIZONTAL MOUNTING
Designed around the popular Model 42 range of rear combination lamps, the Model 41 family boasts all the same features as their larger counterpart but in a smaller more compact package
Share this page
Virtually unbreakable polycarbonate lens In-built retro reflector 0.5m hard wired cable Grey housing

Technical Information

INPUT VOLTAGE RANGE9-33 Volt
CURRENT DRAWIndicator: 0.42A Stop: 0.42A Tail: 0.09A, Reverse: 0.34A
LP RATINGIP66 and IP67
SIZE544 x 100mm
CANDELA RATING71
ADR1/00 AR-E9-00.1135, 6/00 2a-E9-01.1625 (cat 2a), 49/00 R1-S1-E9-02.6256
OTHER49/00 (2) R1-S1-E9-02.6304

Drawings

Product Comprises of

1.94145
2.94147
3.94151H
4.94193
