Narva | 9–33 VOLT MODEL 41 L.E.D REAR DIRECTION INDICATOR AND TWIN STOP/TAIL LAMPS

9–33 VOLT MODEL 41 L.E.D REAR DIRECTION INDICATOR AND TWIN STOP/TAIL LAMPS

9–33 VOLT MODEL 41 L.E.D REAR DIRECTION INDICATOR AND TWIN STOP/TAIL LAMPS

Part No. 94170
16 Designed around the popular Model 42 range of rear combination lamps, the Model 41 family boasts all the same features as their larger counterpart but in a smaller more compact package
Share this page
Virtually unbreakable polycarbonate lens In-built retro reflector 0.5m hard wired cable Grey housing

Technical Information

INPUT VOLTAGE RANGE9-33 Volt
CURRENT DRAWIndicator: 0.42A Stop: 0.42A Tail: 0.09A
LP RATINGIP66 and IP67
SIZE544 x 100mm
CANDELA RATING51
ADR6/00 2a-E9 01.1625 (cat 2a), 49/00 R1-S1-E9-02.6256
OTHER49/00 (2) R1-S1-E9-02.6304

Drawings

Product Comprises of

1.94145
2.94147
3.94193
