Narva | 10–30 VOLT MODEL 20 L.E.D FRONT END OUTLINE MARKER LAMP (WHITE)

10–30 VOLT MODEL 20 L.E.D FRONT END OUTLINE MARKER LAMP (WHITE)

10–30 VOLT MODEL 20 L.E.D FRONT END OUTLINE MARKER LAMP (WHITE)

Part No. 92006
87 Model 20 L.E.D lamps are sonically sealed acrylic lamps with a multi-voltage circuitry of 10–30V and hard-wired leads. Less expensive than the flush mounted polycarbonate 18 series lamps, the 20 series are a low profile surface mounted alternative. These lamps meet the requirements of ADR 74/00 as an amber side marker and are ideal for
Share this page
0.5m hard wired cable In-built retro reflector Rated to 100,000 hours of L.E.D life

Technical Information

INPUT VOLTAGE RANGE10-30 Volt
CURRENT DRAW0.04A
LP RATINGIP66 and IP68
SIZE124 x 39mm
CANDELA RATING24
ADR47/00 31154, 49/00 31153

Drawings
