Narva | 9–33 VOLT MODEL 17 L.E.D REAR END OUTLINE MARKER LAMP (WHITE)

9–33 VOLT MODEL 17 L.E.D REAR END OUTLINE MARKER LAMP (WHITE)

9–33 VOLT MODEL 17 L.E.D REAR END OUTLINE MARKER LAMP (WHITE)

Part No. 91708
92 These ultra slim modern L.E.D markers can be flush mounted with a standard 13mm (1/2”) hole required for cable entry. The lamps have a total thickness of just 9.5mm and incorporate “E” and ADR approved retro reflectors that negate the need for extra reflectors if fitted in accordance with ADR 13 installation requirements.
Share this page
Low profile surface mounted lamp - just 9.5mm 0.5m hard wired cable Sheathed cable and gasket In-built retro reflector

Technical Information

INPUT VOLTAGE RANGE9-33 Volt
CURRENT DRAW0.10A
LEDsRated to 100,000 hours of L.E.
LP RATINGIP66 and IP68
SIZE102 x 44mm
CANDELA RATING40
ADR47/00 IB-E9-02.6272, 49/00 R1-E9-02.6292

Drawings
