10–33 VOLT MODEL 14 L.E.D FRONT END OUTLINE MARKER LAMP (WHITE)
Part No. 91414W
98
Model 14 L.E.D lamps possess all the functions of their larger counterpart, Model 16.
Noticeably smaller in size, these compact economical lamps are simple in construction
and ideal for campers, caravans, trailers and rigid body trucks. They feature multi-voltage
circuitry to suit 12 or 24 volt operation and hard-wired cable.
98
Model 14 L.E.D lamps possess all the functions of their larger counterpart, Model 16.
Noticeably smaller in size, these compact economical lamps are simple in construction
and ideal for campers, caravans, trailers and rigid body trucks. They feature multi-voltage
circuitry to suit 12 or 24 volt operation and hard-wired cable.
Specifications
Technical Information
| INPUT VOLTAGE RANGE | 10-30 Volt |
|---|---|
| CURRENT DRAW | 0.04A |
| IP RATING | IP66 and IP68 |
| SIZE | 90 x 45mm |
| CANDELA RATING | 11 |
| ADR | 49/00 41910 |
| COMPRISES | 91410; 91495; |
Dimensions
