L.E.D Driving Light Bar Spot Beam – 17600 Lumens

L.E.D Driving Light Bar Spot Beam – 17600 Lumens

Part No. 72766
9-32 Volt Built from extremely tough extruded aluminium with virtually unbreakable polycarbonate lenses industrial strength multi-angle bracketry and stainless steel fittings. The bars are assembled within an E.S.D protected environment to maximise the life of the L.E.D resulting in life expectancy in excess of 50 000 hours. Fully sealed and submersible the lamps have an IP66 and IP68 rating.
Share this page
Hard wired cable with Deutsch® connector fitted & matching connector supplied

Technical Information

INPUT VOLTAGE RANGE9-32V
CURRENT DRAW7.6A at 9–32V
LEDs36 x 5 Watt LEDs
LUMENS17600
LP RATINGIP66 & IP68
SIZE967mm

Drawings

Beam Pattern

Product Comprises of

1.36 x 5 watt high powered L.E.Ds
2.Extruded aluminium bar
3.250mm pre-wired lead and Deutsch® connector
