12 Volt 140 Amp Voltage Sensitive Relay

Part No. 61092BL
Automatically connects and disconnects an appliance or circuit at the preset input voltage. Ideal for dual battery systems or to switch high current appliances. Features surge protection, L.E.D indicator, silver tipped contacts for durability and efficiency, with a weatherproof body (IP65). Cut-in: 13.3V Cut-out: 12.7V (5 second delay) 160A at 12V for 60 seconds 140A at 12V continuous load maximum
Automatically connects and disconnects an appliance or circuit at the preset input voltage. Ideal for dual battery systems or to switch high current appliances. Features surge protection, L.E.D indicator, silver tipped contacts for durability and efficiency, with a weatherproof body (IP65). Cut-in: 13.3V Cut-out: 12.7V (5 second delay) 160A at 12V for 60 seconds 140A at 12V continuous load maximum

Specifications

Technical Information
CURRENT DRAWCut-in: 13.3V Cut-out: 12.7V (5 second delay) 160A at 12V for 60 seconds 140A at 12V continuous load maximum
LP RATINGIP65
Dimensions
